Page 14 · 5300 Series TECSource User’s Manual
Menu Description Factory
Default
PID I The integral term of the PID loop. Will only be
available if Gain is set to PID.
0.01
PID D The derivative term of the PID loop. Will only be
available if Gain is set to PID.
0
Sensor Sets the temperature measurement sensor.
Can be Therm 100uA, Therm 10uA, Therm,
LM335, AD590, RTD, or RTD (4-wire).
Therm 100uA
T-Low Lim T-Low Lim is the lower temperature limit. If
operating in T Mode and the actual
temperature drops below this value, the output
will be turned off. Temperature limits not
monitored in R Mode or Ite Mode. Limit
monitoring can also be disabled in software
(see TEC:ENAB:OUTOFF command).
-99°C
T-High Lim T-High Lim is the upper temperature limit. If
operating in T Mode and the actual
temperature rises above this value, the output
will be turned off. Temperature limits not
monitored in R Mode or Ite Mode. Limit
monitoring can also be disabled in software
(see TEC:ENAB:OUTOFF command).
125°C
R-Low Lim R-Low Lim is the sensor low limit. If operating
in R Mode and the actual sensor measurement
drops below this value, the output will be
turned off. R limits are not monitored in Ite
Mode. Limit monitoring can also be disabled in
software (see TEC:ENAB:OUTOFF command).
0.01kΩ
R-High Lim R-High Lim is the sensor high limit. If operating
in R Mode and the actual sensor measurement
exceeds this value, the output will be turned off.
R limits are not monitored in Ite Mode. Limit
monitoring can also be disabled in software
(see TEC:ENAB:OUTOFF command).
45kΩ
Tol Time Tolerance time is the amount of time, in
seconds, that the actual temperature must be
within the set point temperature +/- the Tol
Temp value for the unit to be considered in
tolerance.
5 seconds
