Page 36 · 5300 Series TECSource User’s Manual
Specifications
All values relate to a one-hour warm-up period.
Description
5305 5310 5300-08-24
Drive Channel
Current
Range (A) 5 10 8
Compliance Voltage (V) 12 12 24
Max Power (W) 60 120 192
Resolution (A) 0.01 0.01 0.01
Accuracy (±[% set point + mA]) 0 + 30 0 + 60 0 + 60
Noise/Ripple (mA, rms) < 5 < 15 < 15
Temperature Control
Range (ºC)
1
-99 to 250
Resolution (ºC) 0.01
Thermistor Accuracy (± ºC)
2
0.05
3
AD560 Accuracy (± ºC)
2
0.05
LM335 Accuracy (± ºC)
2
0.05
RTD Accuracy (± ºC)
2
0.05
Short Term Stability (1hr) (± ºC)
4
0.004
Short Term Stability (24hr) (± ºC)
4
0.01
Measurement Channels
Current
Resolution (mA) 10
Accuracy (±[% reading + mA]) 0 + 30 0 + 60 0 + 60
Voltage
Resolution (mV) 10
Accuracy (±[% reading + V]) 0 + 0.05
Sensor
10μA Thermistor
Range (kΩ) 0.1 – 450
Resolution (kΩ) 0.01
Accuracy (± [% reading + kΩ]) 0.05 + 50
100μA Thermistor
Range (kΩ) 0.05 – 45
Resolution (kΩ) 0.001
Accuracy (± [% reading + kΩ]) 0.05 + 5
LM335
Bias (mA) 1
Range (mV) 1730 – 4730
Resolution (mV) 0.1
Accuracy (±[% reading + mV]) 0.3 + 1
1
Software limits. Actual range dependent on sensor type and system dynamics
2
Accuracy figures are the additional error the 5300 adds to the measurement, and does not include the
sensor uncertainties.
3
25°C, 100μA thermistor
4
Stability measurements done at 25°C using a 10kΩ thermistor on the 100μA setting. The number is ½
the peak-to-peak deviation from the average over the measurement period.
