5300 Series TECSource User’s Manual · Page 37
Description
5305 5310 5300-08-24
AD590
Bias (V) 4.5
Range (μA) 173 – 473
Resolution (μA) 0.01
Accuracy (± [% reading + μA]) 0.03 + 0.1
RTD
Range (Ω) 20 – 192
Resolution (Ω) 0.01
Accuracy (± [% reading + Ω]) 0.03 + 0.1
Current Limit
Resolution (mA) 10
Accuracy (±mA) 50
Other
Fan Supply 4 – 12V, 350mA max
TEC Connector Female DB-15
Display Type 2x20 VFD
Computer Interface USB 2.0 Full Speed and RS-232 (DB-9, male)
Power
100V, 120V, or 230V (tumbler select), 50/60Hz
100W 190W 280W
Size (H x W x D) [inches (mm)] 3.5 (90) x 8.5 (215) x 12 (305)
Weight [lbs (kg)] 6.2 (2.8) 7.4 (3.4) 7.4 (3.4)
Operating Temperature +10°C to +40°C
Storage Temperature -20°C to +60°C
