5300 Series TECSource User’s Manual · Page 17
Menu Description Factory
Default
Terminal
Mode
Terminal mode simply echoes any characters
received over the serial or USB interfaces.
No
Msg Term This controls the output message termination,
and can be set to CR/LF, CR, LF, or None.
CR/LF
Sys Menu System Settings Menu
Disp Mode Display mode, which is used to control the
layout on the main screen. Normal will display
four values, typically the set point temperature,
read back temperature, current, and voltage.
Large will display the read back temperature,
sensor, or current, depending on the mode (T,
R, or ITE mode, respectively). When changing
the set point, the set point will be displayed
during the set point change.
Normal
Brightness The vacuum florescent display can be set to
one of eight brightness levels.
100%
Audible
Beep
This setting controls when the unit produces
audible feedback. Set to No to prevent sound,
or Yes or audible alerts such an error
messages.
Yes
Lockout
Knob
Lockout knob allows you to disable knob
operation from the main display. This prevents
accidental changes of the set point. The knob
will always work in the menus regardless of this
setting.
No
Knob Speed Controls the adjustment speed of the knob.
Possible values are slow, medium, and fast.
Slow
ITE Tuning Enables or disables tuning of the ITE current to
prevent over-powering of the heat sink.
Yes
Edit User Cal Enable or disable editing of user calibration
values. This is not a persistent value and will
always resets to No on power up.
No
