INSTALLATION & USER MANUAL ENERGY EFFICIENT WOODSTOVE | PHOENIX
6 | Page
5. FIRE SAFETY
It is OBLIGATORY to respect the National and European rules and local regulations concerning building matter and fireproof rules.
The installation MUST be inspected by a qualified auditor, prior to lighting the woodstove. Also the appropriate local authorities must be
informed.
5.1. Safety distances
Safety distance Α
The side panels and the back must be at least 25cm away from any flammable materials, like furniture,
clothes etc. In case there are no side panels or back panel (that has the air motor), that space must be
increased to at least 40cm.
Safety distance Β
The flue pipes must be at least 25cm away from any flammable materials.
Safety distance C + D
Any flammable materials on the floor must be at least 50cm from the front (distance C) and 30cm from
the sides (distance D) of the stove. In case there are no side panels or back panel (that has the air
motor), distance D must be increased to at least 40cm.
Safety distance Ε
T
he combustion chamber opening must be at least 80cm away from any flammable materials that are
inside the heat radiation zone.
Safety distance F
The minimum distance from the ceiling must be 60cm.
5.2. Wooden beams protection
Given its properties, heat is transmitted through radiation. In case there are any wooden beams inside the radiation zone or in the way of the
hot air, the MUST be properly insulated because the continuous exposure in high temperatures can make them deteriorate faster or even
cause self ignition. Use proper insulation materials that are in accordance with European rules or, in case of high thermal stress you can also
use metal linings.
5.3. General security instructions
Never leave children alone or without supervision near the woodstove when it is lit.
Teach children how to operate the woodstove correctly and safely.
Never touch the external surfaces of the woodstove or the glass when it is lit. There is a high risk of burns!
Due to the self closing door, you have to be extra careful when you are filling the woodstove.
It is forbidden to use the woodstove as a waste incinerator.
Don’t use burned or used wood as fuel.
Remove the ash only after it has completely cooled off.
Ash should be placed outdoors or be disposed in a place where there is no risk of ignition.
Immediately inform your specialized local supplier if you find any malfunction.
Don’t use chemicals or liquids as fire starters.
Do not use ANY fuel other than the recommended.
5.4. Flue security instructions
Prior to installing the woodstove ARTE® the chimney sweep or a qualified technician should check the condition and operation of your
chimney in accordance with the standards EN13384-1 & EN13384-2.
This way you ensure the best conditions for heating without issues.
5.4.1. Basic requirements for proper flue operation
The internal section of the flue must preferably be circular. In a case of square or rectangular
flue, the internal corners should have a radius of at least 20mm. In case of rectangular flue, the
ratio of the sides should be at maximum 1: 1.5.
The flue must be properly insulated and waterproof and constructed of materials with thermal
resistance and resistance to combustion products and any deposits.
The flue must have no constrictions; it must have a vertical path and it should not change in
direction that exceeds 45
o
. (Pic. 5.4.1.1)
Follow the operating instructions supplied with the product to help prevent fire and
protect the environment.
Pic. 5.4.1.1
