Supported IPMI Commands
ATCA-7480 Installation and Use (6806800T17A)
271
8.4.12 Enable Payload Control Command
The Enable Payload Control command enables payload control from the serial debug interface.
8.4.13 Disable Payload Control Command
The Disable Payload Control command disables payload control from the serial debug
interface.
Table 8-40 Enable Payload Control Command Description
Type Byte Data Field
Request Data 1:3 PPS IANA Private Enterprise ID
0x00400A = 16394 (Pigeon Point Systems)
LSB Byte first: byte 1 = 0A, byte 2 = 40, byte 3 = 00
Response Data 1 Completion Code
2:4 PPS IANA Private Enterprise ID
0x00400A = 16394 (Pigeon Point Systems)
LSB Byte first: byte 2 = 0A, byte 3 = 40, byte 4 = 00
Table 8-41 Disable Payload Control Command Description
Type Byte Data Field
Request Data 1:3 PPS IANA Private Enterprise ID
0x00400A = 16394 (Pigeon Point Systems)
LSB Byte first: byte 1 = 0A, byte 2 = 40, byte 3 = 00
Response Data 1 Completion Code
2:4 PPS IANA Private Enterprise ID
0x00400A = 16394 (Pigeon Point Systems)
LSB Byte first: byte 2 = 0A, byte 3 = 40, byte 4 = 00
