IPMI Feature Set
ATCA-7480 Installation and Use (6806800T17A)
310
The MAC addresses of a FRU are stored within the multi-record area of the FRU information.
Artesyn Embedded Technologies has defined a MAC address multi-record for this purpose. For
details, see MAC Address FRU OEM Records on page 310.
9.6.1 MAC Address FRU OEM Records
The Artesyn Embedded Technologies MAC Address record is specified in the following table.
Table 9-7 Artesyn MAC Address Record
Offset Length Description
0 1 Record Type ID. A value of C0h (OEM) shall be used for Artesyn
OEM records.
1 1 End of List/Version
[7] End of List. Set to 1b for the last record
[6:4] Reserved. Write as 000b.
[3:0] Record format version. Write as 2h.
2 1 Record Length
3 1 Record Checksum (zero checksum)
4 1 Header Checksum (zero checksum)
5 1 LSB of Manufacturer ID. Write as CDh.
6 1 Second Byte of Manufacturer ID. Write as 65h.
7 1 MSB of Manufacturer ID. Write as 00h.
8 1 Artesyn Record ID. 01h for Artesyn MAC Address Record.
9 1 Record Format Version. 01h for this specification.
10 1 Number of MAC Address Descriptors (N).
11 N*9 Artesyn MAC Address Descriptors. Refer to XTable 7, Artesyn MAC
Address Descriptor
Table 9-8 Artesyn MAC Address Descriptor
Offset Length Description
0 1 Interface Type. Refer to XTable 8, Interface Type Assignments
1 1 Length Identifier (for example: 6 = 48 bit MAC, 8 = WWPN)
