Removal Procedure
To remove a DIMM module, proceed as follows:
1. Remove blade from system as described in Installing and Removing the Blade on
page 58.
2. Open locks of socket at both sides.
The memory module is automatically lifted up.
3. Remove module from socket.
4. Repeat steps 2 to 3 in order to remove further memory modules.
2.5.2 SSD Carrier and MO297 SSD Modules
ATCA-7480 provides a modular solution for up to three MO297-A compliant SSDs. Each SSD is
connected to the Intel Wellsburg PCH via a SATA interface. The modular approach consists of a
riser card, which provide up to three sockets for SSDs and the MO297-A compliant SSDs.
The SD module is an accessory kit and is not part of the default ATCA-7480. The following
procedure describes the steps to install/remove the MO297-A compliant SSD module.
Before mounting the storage on ATCA-7480, the riser card and SSDs should be pre-
mounted.
