The location of the MO297 SSD module carrier/riser is illustrated in the following figure.
Figure 3-5 Location of MO297 SSD Module Connector
P30
P31
P30
P32
P22
P20
P23
ZONE 1
MO-297 Carrier
J11 DIMM 1
