Arturia MatrixBrute - Control Voltages I;O; Audio I;O

VCO1 Pitch 0 - 10V
VCO1 Ultra Saw +/- 5V
VCO1 Pulse Width +/- 5V
VCO1 Metalizer +/- 5V
VCO2 Pitch 0 - 10V
VCO2 Ultra Saw +/- 5V
VCO2 Pulse Width +/- 5V
VCO2 Metalizer +/- 5V
Steiner Cutoff 0 - 10V
Ladder Cutoff 0 - 10V
LFO 1 amount 0 - 10V
VCA 0 - 10V
Gate I/O (TS)
Gate (TS) 0 – 5V
Sync (TRS)
Gate 0 – 5V
Audio I/O
Label Jack Level Note
Master
Out L/R
Mono TS +4dBu
Audio In Mono TS
Line = 0-20dB Inst
= 0-40dB
68kΩ
1.1MΩ
Insert
TRS = Tip=Send; Ring =
Return; Sleeve = Gnd
+4dBu
54 Arturia - MatrixBrute Manual - MIDI
