Installing the Chassis
Chapter 2
10 Aruba 200 Mobility Controller 0500215-01
Installation Guide January 2006
NOTE: Aruba ships a country appropriate cable with the Aruba 200 Mobility
Controller. However, any power cord rated for the Aruba 200 Mobility
Controller power consumption and which conforms to grounded
electrical standards in the country where the product will be operated can
be used (see “Specifications” on page 13).
Use of a power line conditioner or Uninterruptible Power Supply (UPS) can
decrease or mitigate problems caused by power service fluctuations. Make sure
that the output of any power shaping device is compatible with the Aruba 200
Mobility Controller power supply.
N
OTE: Additional power adapters can be ordered separately. The part number
for spare Aruba 200 Mobility Controller power adapters is A200-AC-S.
Verifying the Installation
After the Aruba 200 Mobility Controller is installed and connected to power, verify
the following:
1. Check that the system Power LED lights solid green immediately upon power
up and remains solid green during and after bootup.
N
OTE: The system Status LED remains off until you perform the initial
setup.
For more information on LED behavior, see “System Indicator LEDs” on
page 4.
2. Connect appropriate network cables (see “Fast Ethernet WAN Port” on
page 4 and “Gigabit Ethernet LAN Port” on page 5 for cable information).
3. Perform the initial setup as described in the Aruba Quick Start Guide (which
is included in the Accessory Kit).
