11
After successfully connected, the BT LED will stay on and you should be able to hear the sound coming out
from the connected Bluetooth device, and the connected passive speaker will have no sound.
You can connect a second BT receiver device once the rst device has been successfully connected. Press
the Reset button on the back or press the BT TX button on the remote controller will trigger the device
to enter pairing mode for the second BT receiver device. The connection process is the same as the rst
device.
Connecting the second device will take 20 to 50 seconds, please be patient.
Once connected, both BT receiver device will have sound output.
To disconnect the Bluetooth connection, quickly press the Reset button twice to disconnect all the
connection.
7.3 Line in Mode
You can connect any analog device with line out to play music from B50. You will need to switch to Link in
mode with the Mode button on the device, use the remote controller or in the Go Connect APP. The Line
LED will turn on when you in Line in mode.
You can also stream Line in audio through Bluetooth and listen from connected Bluetooth receiver devices
such as Bluetooth speakers or Bluetooth headphone.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Arylic B50 and is the answer not in the manual?

Arylic B50 Specifications

General IconGeneral
Amplifier TypeClass D
Input Impedance47kΩ
Bluetooth Version5.0
WiFiYes, 2.4G IEEE 802.11 b/g/n
Bluetooth CodecSBC, AAC
Frequency Response20Hz-20kHz
Streaming ProtocolsSpotify Connect, Airplay, DLNA
Audio InputsRCA, Optical
Audio OutputsSubwoofer out
Bluetooth Range10m
Power Supply24V/4.16A
Wireless2.4G WiFi, IEEE 802.11 b/g/n
