5170 Quad-Ethernet Module Types of Data/Control Appendix-2
Types of Data/Control found on Web pages
The following types of data and control are provided on 5170 QEM web pages, depending on the connected devices.
Dashboard web page
▪ Switch Status, Active Alerts, Timers
▪ Transfer Switch – Control Capability
▪ Voltage, Frequency, and Current Monitoring
▪ Transfer Switch / Generator Statistics
If equipped with meter device
▪ Energy Consumption – Net KWH, KVAR, KVA
▪ Transfer Switch Rated Current Utilization
▪ Power Measurement – KW, KVA, KVAR, PF
▪ Voltage (L-L and L-N), Frequency, and Current Measurement
Transfer Switch Details web page (settings for view only)
▪ Pickup and Dropout Voltage Settings
▪ Frequency Trip Settings
▪ Engine Exerciser Settings
▪ Switch Status
▪ Active Alerts and Timers
▪ Transfer Switch and Engine Status
Power Meter Details web page (settings are view only)
▪ Energy Consumption
▪ Switch Status, Active Alerts, & Timers
▪ Historic KW Demand
▪ Maximum Load Demand Chart
▪ Power Measurement – KW, KVA, KVAR, PF
▪ Voltage, Current, Frequency, Power, and PF Measurement
▪ PT and CT ratios
Event Log page
Events page shows the controller events logged into the 5170 QEM. Data included: event type, cause, timestamp.
Configuration web page
▪ There are two Ethernet Configuration pages. One is viewable only; the other allows setting changes (Admin level).
▪ Viewable and editable are IP, TCP, and Communication Settings as well as SNMP and email settings.
▪ User can also change device names & locations (these are only changes that can be made to downstream devices)
from the configuration → device pages.
▪ The Configuration section is where a user can change the passwords (see page 2-1).
▪ Firmware upgrade access
About page
▪ The About page provides firmware versions of the 5170 QEM and devices that are connected downstream.
