Installation of the Base Station
INSTALLATION GUIDE
IP-DECT Base Station and IP-DECT Gateway
Figure 8. Fixing the mounting bracket to a wall.
TOP
100 mm (IPBS3, IPBS2, DB1)
65 mm (IPBS1, BS3x0)
Ceiling
0
11
It is critical that the mounting bracket is securely and firmly attached to the wall or ceiling, this is
especially important if it is mounted more than 2 m above the floor:
• Make sure that there is a significant increase of the required torque when the screws are fully
engaged.
• Test that the mounting bracket is securely attached by firmly pulling the back-plate from the
wall/ceiling.
3.2.2 Fix the Mounting Bracket to a Ceiling
Fixing to a ceiling is done in the same way as the a wall, see 3.2.1 Fix the Mounting Bracket to a Wall, page
16. When the base station has to be positioned above a suspended ceiling, make sure that the front of the
base station points downwards.
3.2.3 Fix the Mounting Bracket to a Pole or Beam
The mounting bracket can be fixed to a pole (diameter > 45 mm) or a beam (wider than 50 mm) by means of
a strap or flexible metal band less than 30 mm wide. The strap or flexible metal band is not included in the
box.
17
TD 92989EN / 25 January 2021 / Ver. E
