Description
INSTALLATION GUIDE
IP-DECT Base Station and IP-DECT Gateway
Power Distribution
The IPBS1 can be powered using the following methods:
• Power over Ethernet, IEEE 802.3af
• A local AC-adapter
For more information about power distribution, see 3.3 Power the Base Station, page 23
Software
For information on how to update the software in the IPBS1, see the applicable Installation and Operation
Manual for the IPBS1.
Connectors
• Two 8-pin RJ45 modular jacks for LAN/PoE and powering
• A 6-pin RJ12 modular jack for factory testing
LEDs
Status of LED1 (lower LED) Description
Steady Green Operational
Flashing fast amber Download of firmware in progress.
Steady Amber TFTP mode
Alternating red/green No Ethernet connection
Status of LED2 (upper LED) Description
Not lit IPBS1 operational and no traffic on the IPBS1.
Steady green IPBS1 operational and traffic on the IPBS1.
Flashing slow green Fully occupied with traffic.
Flashing red No air synchronization - searching for air sync
candidates.
Flashing fast red Download of RFP software in progress.
Alternating red/green RFP not initialized.
2.1.2 IPBS1 with External Antennas
The IPBS1 is available with two omni-directional external antennas. Other external antennas can be
mounted as well. This section contains the differences between the IPBS1 with internal and external
antennas. For all other information see 2.1.1 IPBS1 with Internal Antenna, page 2.
Contents of the Box
The box in which the IPBS1 is packed contains:
• An IPBS1 for external antennas
3
TD 92989EN / 25 January 2021 / Ver. E
