ASCOM T942C/2 User Manual

TD 91684GB
16 April 2015 / Ver. G
Installation Guide
T942C and T942C/2 Central Unit
7
1.4 Installation
T942C should be placed in a dry environment with a temperature range of 0 to +40°C.
1.4.1 Mounting
IMPORTANT: The unit must be mounted by trained personnel.
IMPORTANT: The unit must be mounted to a solid vertic
al wall with the bottom facing the
floor.
Bottom
Top
The illustration below shows the dimensions in mm for mounting the unit.
9 9
275
56.5
188.5
65
130
112
Dimensions (H x W x D)
275 x 130 x 60 mm
Figure 4. Mounting dimensions in mm.
NOTE: To facilitate service after the unit is installed
, we recommend a free space of about
150 mm above and 50 mm below the unit.
