1
Thank you for choosing an ASCON controller
The instruments of the XS series belong to the last generation of
microprocessor based controller, are universal, very powerful but
simple to use.
They are fitted with AUTO-TUNE and EXPERT-TUNE, an auxiliary for
system start-up, and serial communication for introduction into a
distributed control network.
They are complete because all possible variables are always present.
Configuration of the instrument permits determination of the operating
mode according to the application required.
1.1 Identification of model
1 • IDENTIFICATION OF MODEL
Power supply
100 …240 V 50/60 Hz
16 …28 V 50/60 Hz and 20…30 Vdc
Serial communications
None
20mA C.L. Std Ascon protocol
Retransmission output Y4
None
Fitted (4...20 mA or 0...10 Vdc)
Set point
Standard
(up to 4 mem. or Loc./Rem.)
Time-programmable
(11 segments)
3
5
0
1
0
1
0
1
Model code
OPTIONS
A
B
C
D
XS -
A B C D
Configuration code Beginning and end
of scale
20mA C.L. Modbus/Jbus protocol
2
275.8
275.8
504
