Ascon tecnologic XS Series User Manual

7
28 screw terminals M3.5
Plate pin
Plate screw
3 gilded
terminals for
input signals
Cold joint
compensation
thermometer
Wiring
protection plate
2
Rotate
downwards
1
Lift the plate to free
the pin
2
Depress the plate to
engage the pin
1
Rotate
upwards
With eyelet
terminals
6.9 max.
With tinned wire
6 ÷ 7
With fork
terminals
6.9 max.
Cable
section
wires
N°
0.25 ÷ 2.5
AWG
22 ÷ 14
2
1
2
Preferential
7
A • Terminal board B • Freeing the terminals
D • Protecting the terminal boardC • Effecting the connections
4 • ELECTRICAL WIRING
