Ubiquity Router family - User’s guide
The following behaviors are defined:
- Steady lighted
- Blinking
- Continuous sequence of a blink codes with a short pause in between
to report a status
- Single sequence of a blink code to report an event
Active when pressing the RESET button or when in
presence of a not recoverable hardware fault.
Active when the Ubiquity Router device is properly
powered
Ubiquity started and connected to the server
Ubiquity started but NOT connected to the server
Ubiquity started and connecting to the server
Ubiquity started but not connected to the server
because not associated to any Domain
connection attempt to a different domain than the
first of the initial registration
Configuration from USB stick successfully complet-
ed
User credential for Domain access not valid
Ubiquity Router device Update from USB stick suc-
cessfully completed
Ubiquity Router device Updated from USB Stick
failed
Ubiquity Runtime execution error, will follow a
system restart
USB stick data format not correct or unknown er-
ror
Active when at least one Control Center client is
connected to the Router, otherwise off
These LEDs are directly connected to the serial
port Rx/Tx signals and they show traffic through
the lines
2G/3G/3G+
MODEM CON-
NECTION
The modem has not detected network signal.
The modem has detected a weak signal from the
network.
The modem has detected a strong signal from the
network.
SIM error (e.g. wrong PIN).
2G/3G/3G+
MODEM ACTIV-
ITY
Modem currently connected.
