ASEM Ubiquity RK11 User Manual

60
SECTION 8 - Technical specifications
Table 2
System software characteristics
Table 3
System hardware characteristics
Table 4
Electrical characteristics
Table 5
Mechanical characteristics
6.1 Technical specifications
System software characteristics
Integrated sys-
tem software
Operating System
Microsoft Windows Embedded Com-
pact 7 (C7P)
Other software
ASEM Ubiquity runtime firmware
System hardware characteristics
Motherboard
Model
All-in-one, ASEM R171
RTC
Hardware with battery backup
CPU RK10
Processor
ARM Cortex A8 - Freescale i.MX535 - 1 GHz
Memory bus
400MHz
CPU RK10ET
Processor
ARM Cortex A8 - Freescale i.MX537 - 800 MHz
Memory bus
400MHz
System memory
Type / Size / Socket
512 MB, / DDR3-800 / Soldered
Serial interfaces
Type
1 x RS232/422/485 (DB15M) software se-
lectable
Optoisolation
Yes
Ethernet interfaces
Type
1 x 10/100Mbps WAN (RJ45) with Link/Activity
leds
1 x 100Mbps LAN (RJ45) with Link/Activity leds
2G/3G/3G+ modem
(only for RK/RM11)
Type
provides data service under global
GSM/GPRS/EDGE/WCDMA networks
(14.4Mbps downlink data rate)
USB interfaces
Type
1 x USB 2.0 (TYPE-A, host port, software
switch off)
Mass storage
Internal / not re-
movable
NAND-FLASH:
256 MB (Read Only) for Operative System and
other system software.
eMMC:
2/4 GB - 8 bit v. 4.4 compatible (application
software and Ubiquity Runtime)
Battery
Type
Coin (CR1220 3V) removable non rechargeable
Lifetime
3 years
Buttons, LEDs and
keys
Reset Button
Factory Recovery
Button
System
User
LEDs
Reset
Power
Run / Stop
Remote Connection
COM Rx
COM Tx
2G/3G/3G+ Modem. activity
Modem connection
Electrical characteristics
Power supply
Type
Integrated on board, auto ranging
Input voltage
9÷36 VDC with 3 poles connector
Protections
Anti-inversion polarity, over-voltage, fuse soldered
on the board
These devices are intended to be connected to a “Secondary Circuit Overvoltage Category II”
Mechanical characteristics
Case
Type
Book mount
Material
Steel, white zinc galvanizing
