Ubiquity Router family - User’s guide
Table 6
Environmental characteristics
Table 7
Panel antenna characteristics
Table 8
Wall mount Panel antenna characteristics
Environmental characteristics
Temp. RK10,
RM10, RK11,
RM11
Operation
-0° ÷ +50°C
Storage
-20° ÷ +60°C
Temp. RK10ET,
RM10ET
Operation
-20° ÷ +70°C
Storage
-30° ÷ +80°C
Temp. RK11ET,
RM11ET
Operation
-20° ÷ +60°C
Storage
-30° ÷ +80°C
Humidity
Operation/Storage
80% (non-condensing)
Panel antenna characteristics
Electrical
Frequency range
800MHz to 2200MHz
Bands
GSM-DCS-PCS-UMTS-CDMA-GPRS-EDGE-HSPA
VSWR
≤ 2.3
Polarization
Linear
Power handling
20 W
Impedance
50 Ohms
Connector
Straight SMA(M)
Environmental & Mechanical
Temperature
-40° to +85°C
Radome color
Black
Radome material
Pu
Weight
6 g
Wall mount Panel antenna characteristics
Cellular
Frequency
(MHz)
824 ~ 896
880 ~ 960
1710 ~ 1880
1850 ~ 1990
1710 ~ 2170
Peak Gain (dBi)
Free Space
-0.7
-0.9
1.7
2.5
2.2
L - Bracket
4.0
3.6
2.8
3.8
3.3
Average Gain (dBi)
Free Space
-5.7
-5.3
-2.2
-2.1
-2.3
L - Bracket
-1.7
-1.8
-2.2
-1.7
-1.9
Efficiency
Free Space
27%
30%
61%
62%
60%
L - Bracket
69%
66%
59%
68%
65%
Impedance
50Ω
Polarization
Linear
Radiation Pattern
Omni
Input Power
50 W
Mechanical
Dimensions
Height 248 ± 5 mm
Base Diameter
17.08 ± 0.2 mm
Whip Diameter
4 ± 0.2 mm
Casing
ABS
Connector
SMA Male
Environmental & Mechanical
Temperature range
-40° to +85°C
Humidity
Non condensing 65°C 95% RH

ASEM Ubiquity RK11 Specifications

General

Brand	ASEM
Model	Ubiquity RK11
Category	Network Router
Language	English
