47
Figure 45
OUT0 – WAN connection enabling signal-
ling example
Figure 46
OUT0 – WAN connection enabling signal-
ling example
Figure 47
OUT0 – Remote assistance service running
example
Figure 48
OUT0 – Remote assistance service running
example
3.10.3 OUT0 - WAN connection enabled signalling
DIGITAL
IN / OUT
5
6
OUT0A
OUT0B
24V DC
max
200mA
DIGITAL
IN / OUT
5
6
OUT0A
OUT0B
24V DC
max
200mA
230V AC
3.10.4 OUT0 – Remote assistance service running
DIGITAL
IN / OUT
7
8
OUT1A
OUT1B
24V DC
max
200mA
DIGITAL
IN / OUT
7
8
OUT1A
OUT1B
24V DC
max
200mA
230V AC
