Rear Panel
Fig. 1-2 Rear Panel
Slot Description
WPS Enables scanning for available WPS client device
USB USB 3.0 host connector
RESET Reset/Reboot this Cable modem
LAN 1 / 2 / 3 / 4 Ethernet 10/100/1000 Base-T RJ-45 connector
CABLE RF F-Connector
12VDC 12V DC-IN Power connector.
Table 1-2 Rear Panel description
