49
ADJUSTMENTS AND PERIODIC MAINTENANCE
EN
EN
EN
EN
EN
REAR DRUM BRAKE (NGS2 - NGS3)
The wear of disc and pads is automatically
compensated, therefore it has no effect on the operation
of the brake and does not require registration.
If there is excessive stroke and the lever is too close
to the grip when operating the brake, it could be due
to the presence of air in the circuit or to irregular
operation of the brake.
Effective braking action should begin after
approximately 1/3 of the brake lever stroke.
REAR DISC BRAKE WITH COMBINED FUNCTION
(only NGS
3)
The scooter model NGS
3 uses the dual braking:
actuating the rear brake automatically also activates
the front brake.
The distribution has prevalence on the rear and the
adjustment of the rear adjusting nut affects both
wheels.
WARNING
In case of brake malfunctions check brake pad wear, if thickness is reduced both are
to be replaced at an authorized workshop.
WARNING
After replacing the pads operate the brake lever several times to reposition them
and bring the lever to the right position.
NGS_Rev00_EN.indb 49NGS_Rev00_EN.indb 49 05/06/2020 11:28:4905/06/2020 11:28:49
