GAS SECTION
TYPES OF GASES
The gases normally used may be grouped, in view of their
features ,in three families:
-L.P.G.(in cylinders) G30
-NATURAL GAS(methane) G20
-CITY GAS G110
INSTALLATION
The appliance is predisposed and adjusted to operate with the
gas indicated on the specifications plate applied onto the
appliance.
If the appliance must be operated with a gas different than that
indicated on the plate,it is necessary to execute the following
operations:
-gas connection
-replacement of the injectors
-regulating of the minimum
GAS CONNECTION
The connection must be executed by qualified technician
according to the relevant standard.
The fitting (fig.18)is made up of:
√1 elbow fitting“A”
