GENOAD8X-2T/BCM
26 27
English
ATX Power Connector
(24-pin ATXPWR1)
(see p.6, No. 4)
3V
3V
GND
GND
5V
5V
GND
PWROK_PS
5VSB
12V
12V
3V
121
13
24
3V
-12V
GND
PSON#
GND
GND
GND
5V
5V
5V
GND
N/A
is motherboard provides a
24-pin ATX power connector.
To use a 20-pin ATX power
supply, please plug it along
Pin 1 and Pin 13.
ATX Power Connectors
(8-pin ATX12V1)
(see p.6, No. 6)
(8-pin ATX12V2)
(see p.6, No. 5)
(8-pin ATX12V3)
(see p.6, No. 7)
4
8
1
5
12V
GND
is motherboard provides
three ATX power connectors.
Graphics 12V Power
Connector
(6-pin GFX_12V1)
(see p.6, No. 24)
13
46
+12V
GND
GND
Detective Pin
is motherboard provides
a 6-pin Graphics 12V power
connector. * Install the PSU’s
power cable to this connector
when 4 graphics cards are
installed.
Intelligent Platform
Management Bus Header
(4-pin IPMB1)
(see p.6, No. 37)
IPMB_SDA
IPMB_SCL
No Connect
GND
is 4-pin connector is used
to provide a cabled baseboard
or front panel connection
for value added features and
3rd-party add-in cards, such
as Emergency Management
cards, that provide manage-
ment features using the IPMB.
Serial General Purpose
Input/Output Headers
(7-pin SATA_SGPIO1)
(see p.6, No. 25)
(7-pin SATA_SGPIO2)
(see p.6, No. 27)
1
SLOAD
GND
GND
SDATAOUT
ese headers support Serial
Link interface for onboard
SATA connections.
