M8
43
English
No. Description
1 System Panel Header (PANEL1)
2 LPC Debug Header (LPC1)
3 SATA3 Connectors
(SATA3_1, SATA3_2, SATA3_3, SATA3_4, SATA3_5, SATA3_6)
4 Clear CMOS Jumper (CLRCMOS1)
5 Auxiliary Fan Connector (AUX_FAN1)
6 USB 2.0 Header (USB_1_2)
7 mini-PCI Express Slot (MINI_PCIe1)
8 WiFi-802.11ac Module
9 Front Panel Audio Header (HD_AUDIO1)
10 CPU Fan Connector (CPU_FAN1)
11 ATX 12V Power Connector (ATX12V1)
12 Chassis Fan Connector (CHA_FAN1)
13 ATX Power Connector (ATXPWR1)
14 2 x 204-pin DDR3 SO-DIMM Slots (DDR3_A1, DDR3_B1)
15 USB 3.0 Header (USB3_3_4)
