CL3500 Series
Installation Instructions
Cylindrical Lockset
FM237 03/19
Copyright © 2012, 2019, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-607-5703 • techsupport.corbinrusswin@assaabloy.com
Attention Installer
Please read these instructions carefully to prevent missing important steps.
Notes
• Improper installation may result in damage to lock and void factory warranty.
• Other product brand names may be trademarks or registered trademarks of their respective owners
and are mentioned for reference only.
TOC Table of Contents
1 Standard Installation ............................................................3
a Install Latchbolt, Lockbody and Inside Trim ......................................3
2 Door and Frame Preparation ....................................................4
a Mark Door .......................................................................4
b Drill Door ........................................................................4
c Install Strike .....................................................................4
3 Optional Installations ............................................................5
a For CL3580 and CL3581 Function Only ...........................................5
4 Cylinder Installations ............................................................5
a Interchangeable Core Installation ................................................5
b Interchangeable Core Removal ..................................................6
c Standard Cylinder Installation ...................................................7
d Conversion Kit ...................................................................7
5 Lever Removal Installation .......................................................8
