80-9380-8002-152 Rev. 07/09
Interior
Exterior
In
Swing
Exterior
Out
Swing
LATCHING
SPEED VALVE
BACKCHECK
INTENSITY VALVE
CLOSING
SPEED VALVE
SPRING POWER ADJUSTER
(1/4 ALLEN WRENCH)"
Size of Door
(Approx.)
Equivalent
Closer Size
DC8200 SPRING POWER ADJUSTMENT CHART
2 4 (712)
2 6 (764)
3 0 (915)
3 6 (1067)
' "
' "
' "
' "
3
4
5
6
2 6 (764)
3 0 (915)
' "
' "
2 6 (764)
3 0 (915)
3 6 (1067)
4 0 (1219)
' "
' "
' "
' "
Spring Power Adjustment
DC8200 Size1thru 6 Adjustment See Chart
All DC8200 closers are factory set at an approximate
Adjust closer as necessary for door size using this chart.
Readjustment may be required to suit prevailing conditions.
Size 3.
Locate spring power adjuster from Illustration below
Backcheck Intensity Valve
Turn valve COUNTER-CLOCKWISE to reduce backcheck
or CLOCKWISE to increase backcheck. (Backcheck should
be set to give a soft cushioning action, not a sudden stop.)
L
a
t
ch
C
l
o
s
i
n
g
S
p
e
e
d
B
a
c
k
c
h
e
c
k
D
e
l
a
y
e
d
A
c
t
i
o
n
Option
M71
Full Cover
(Standard)
Latching Speed Valve
After closing speed has been obtained, turn latching speed valve
CLOCKWISE to SLOW latching or COUNTER-CLOCKWISE to
SPEED latching for last 2 to 5 of door travel.
NOTE: Set combination of CLOSING and LATCHING speeds to
between3and 7 seconds Use of door by handicapped,
elderly or small children may require even greater
closing time.
" "
Closing Speed Valve
To adjust speed of door closing from fully open toaposition
2 to 5 from closed, turn Closing Speed Valve CLOCKWISE
to SLOW closing, COUNTER-CLOCKWISE to SPEED
closing.
" "
(1/8 Allen Wrench Provided)
(1/8 Allen Wrench Provided)
Delayed Action Valve
Turn valve CLOCKWISE to SLOW closing, COUNTER-
CLOCKWISE to SPEED closing. Delayed action may be
adjusted from 20 seconds to 90 seconds, depending on
degree of door swing. Delay occurs at the beginning of the
door closing cycle from fully open down to 70°, where the
closing speed valve then begins its control.
(1/8 Allen Wrench Provided)
OPTION M71
DELAYED
ACTION VALVE
Insert is removable.
Place in unused opening.
2-7
7-11
11-15
15-17
Spring Power
Adjustment
No. Full Turns
Clockwise
4
DC8210 x A3 HD Parallel Arm Installation Instructions
Date Stamp
(on end of closer)
MM-YY
MM = Month
YY=Year
Slip cover over closer.
Hold tightly against QUIK-INSTALL® Bracket surface.
Secure on each side with 6-32 x 1/4 PBHMS screws."
Installing Cover
ADJUST CLOSER
F
D
C
E
B
This P age
Previous Page (,)
2
A
F
3
Copyright © 2006, 2009, Corbin Russwin, Inc., an ASSA ABLOY Group company. All
rights reserved. Reproduction in whole or in part without the express written permission
of Corbin Russwin, Inc. is prohibited.
