Installation Diagrams
LBM WIRING
White
Orange Normally Open
Green Normally Closed
Common
DIAGRAM 4: LATCHBOLT MONITORDIAGRAM 3: FAIL SAFE TO FAIL SECURE
DIAGRAM 5: FACEPLATE INSTALLATION
a
b
c
Loosen screws, but do not
remove them
Move screws to the Fail Safe
position as shown
Tighten screws
DIAGRAM 7: VERTICAL ADJUSTABILITY
DIAGRAM 6: VERTICAL ALIGNMENT
Fail Safe*
Centerline
*Fire rating only applies to Fail
Secure units. Conversion to Fail
Safe negates fire rating on 8300
White
Orange
Green
