Assa Abloy Yale YRD216-ZW3 User Manual

29
3
Relock time
1 byte
0x0A (10
seconds)
[0x8002,
0x810A,
0x8004,
0x8109,
0x8103 &
0x8113]
0xB4 (180
seconds)
0x1E (30
seconds)
Adjust the time your
lock will auto relock.
43
0x01 (1
seconds)
[0x8104] ¹
4
Wrong Code
Entry Limit
1 byte
0x03
0x0A
0x05
[0x8002,
0x810A,
0x8004,
0x8109,
0x8103 &
0x8113]
Adjust the limit for
wrong code entries
allowed by your
lock.
61
0x03
[0x8104]
5
Language ²
1 byte
0x01 (English)
0x03
(French)
0x01
(English)
Set the language to
English (1), Spanish
(2), or French (3).
60
7
Shut down time
1 byte
0x0A (10
seconds)
0x84 (132
seconds)
0x3C (60
seconds)
Adjust the time your
lock is shutdown
after reaching its
wrong code entry
limit.
80
