Assa Abloy Yale YRD216-ZW3 User Manual

30
8
Operating mode
³
1 byte
0x00 (Normal
Mode)
0x02 (Privacy
Mode)
[0x8002,
0x8004,
0x8109 &
0x810A]
0x00 (Normal
Mode)
Set the Operating
Mode to normal
mode(0), vacation
mode(1), privacy
mode(2). [0x8002,
0x8004, 0x8109 &
0x810A]
75
Set the Operating
Mode to normal
mode, keypad
disable mode or
passage mode.
[0x8104]
76
0x03
(Passage
Mode)
[0x8103,
0x8104 &
0x8113]
Set the Operating
Mode to normal
mode, vacation
mode, privacy mode
or passage mode.
[0x8103 & 0x8113]
83
11
One Touch
Locking
1 byte
0x00 (Disable)
0xFF (Enable)
0xFF (Enable)
Set One Touch
Locking feature to
enable or disable.
51
12
Privacy Button
⁴
1 byte
0x00 (Disable)
0xFF (Enable)
0x00
(Disable)
Set Privacy Button
feature to enable or
disable.
48
13
Lock Status LED
1 byte
0x00 (Disable)
0xFF (Enable)
0x00
(Disable)
Set Lock Status LED
feature to enable or
disable.
49
