¹ Even though the lock accepts value 0x01 for Auto Relock Time, we limit the lock’s minimum to value of 0x03. Therefore, if
user tries to set Auto Relock Time to values 0x01 or 0x02, it will always report back value of 0x03.
² Only supported by YRC/D226/256/652/622/642, NF-YRC/D622, YRC/D622/642-NN
³ When Operation Mode feature is set to Passage Mode, this also results in disabling the following configuration parameters 2
(Auto Relock feature). For YRD410/420/430/450, the Passage Mode feature can only be set when user holds the inside button.
For YRC/D622/642 & YRC/D622/642-NN, the Passage Mode feature can only be set when Passage User Pin Code is used to
unlock the lock.
⁴ Only supported by YRC/D216/226/256/652/622/642, NF-YRC/D612/622, YRC/D622/642-NN
⁵ Only supported by YRC/D622/642 & YRC/D622/642-NN
⁶ When this Escape Return Mode feature is enabled, this also results in disabling the following configuration parameters 2 (Auto
Relock feature) and 11 (One Touch Locking feature).
⁷ Only supported by YRD410/420/430/450. This requires additional Hardware and calibration within the Yale Access App.
⁸ The Door Propped value is represented as seconds X 10. (i.e., a value of 4 would mean a door propped timer of 40
seconds).
