Command Class Application Status, Version 1
This command class has been implemented per the Z-Wave
™
Specification.
Command Class Transport Service, Version 2
This command class has been implemented per the Z-Wave
™
Specification.
Command Class Supervision, Version 1
This command class has been implemented per the Z-Wave
™
Specification.
Command Class Indicator, Version 3*
* This command class requires security.
The indicator feature is set by using Indicator ID 0x50 to identify the node and
Property ID 0x02 or 0x03, 0x04 and 0x05.
Table 9 – Lock UI for Indicator Set Overview
Indicator Set
Lock Exterior
Lock Interior
OFF
Keypad LED is OFF
Inside LED OFF
ON
YRC/D226/256/652/622/642,
NF-YRC/D622,
YRD410/420/430/450, &
YRC/D622/642-NN:
Numbers 0-9 on Touch
Screen Flash
YRC/D216 & NF-YRC/D612:
All buttons Flash
Inside LED Flashes
In order to set the Indicator ID 0x50 with Property 0x02, set values to 0x00 for off
and 0x01…0x63 or 0xFF for on.
In order to properly set the Indicator ID 0x50 with Properties 0x03, 0x04 and 0x05,
we had to map the values to our lock’s specific blink rate.
Table 10 – Minimum Values for Indicator Set Property IDs 0x03, 0x04, & 0x05 to trigger Lock UI
Property ID 0x03
(On/Off Periods) Fixed
Value
Property ID 0x04
(On/Off Cycles)
Minimum Value
Property ID 0x05 (On
time within an on/Off
period) Fixed Value
0x14*
0x00...0xFF (per Z-
Wave
™
Spec)
0x0A*
*NOTE: If Property IDs 0x03 and 0x05 are set to value other than the above, then
the lock will blink at the different number of cycles than what you have set. *
