4. Unit operation
Page 23 of 40 issue date 24.02.2021, rev. 10.1
Figure 4.6. Screenshot sample view for electrotherapy sequences
Symbol Description
1 Indication of the treatment elapsing time and sequence step
4.4.2 Combined therapy
Figure 4.7. Screenshot sample view for combined therapy
Symbol Description
1 US head parameters and current name / Program name
2 Output power / Output power density
3 Output circuit identification and amplitude value
4 Presentation of the treatment elapsing time
5 Information field
6 Tab field – channel 2
