4. Unit operation
PHG 300A / 301A User Manual Page 28 of 40
4.7 Manual mode operation
Symbol definition and parameter range are specified in the PhysioGo – Technical description manual.
Step Description
1.
Switch on the unit.
2. Choose the treatment channel 1, 2 or 3.
3.
Select the therapy according to the point 4.3.
4.
Press the field
Manual mode
5.
In the case of electrotherapy and combined therapy select the current type.
6.
Using the keys select the parameter for edition, using the keys set its value.
7. Prepare the patient for the treatment according to indications in point 4.1.
8.
Press the key
9.
For electrotherapy, using the keys choose the circuit, using the keys set the current
or voltage amplitude.
10.
If it is necessary, during treatment procedure, using the keys set the amplitude.
If it is necessary to interrupt the treatment procedure (pause), press the key . To resume the treatment
procedure, it is recommended to follow the instructions shown on the display.
4.8 User programs
The user has the possibility to save in to the device memory own sets of treatment parameters in the form of
programs.
Saving of user program:
Step Description
1.
Prepare the unit to work in manual mode (steps 1 – 5 see section 4.7).
2.
Set the program parameters.
3.
Press the button from main menu.
4.
Select the item number under which the program will be saved. Confirm your choice with the key
5.
Enter the program name. Press the key or button
The user-defined programs are selected in the same way as preset treatment programs. In Program modes menu
select the option User programs.
Edition of user program:
Step Description
1. Prepare the unit to work in the program mode (see section 4.5).
2.
Select the option User programs from Program modes menu. Confirm by the key or once again
press the selected field.
3.
Select the program for edition.
4.
Press the button from main menu.
5.
Select the action – Edit.
