Hose Assembly
For best results and to maintain proper operaon, use only
original parts and hoses.
1. To connect the hose secons, wet the ends in the pool
water, then twist and push the female ends onto the
male ends.
2. Connect the leader hose to the cleaner swivel. See
Figure 3.
3. The hose should reach from where the cleaner is
connected to the farthest point of the pool, plus one
secon and the leader hose.
4. Install the hose oat onto the second length of hose.
The oat should be placed 50.8 cenmeters (20 inches)
above the cleaner. See Figure 4.
5. Make sure that all connecons are snug.
6. The overall length of hose needed will be determined
by the distance from the point at which you aach the
hose to the sucon port to the furthest point in the
pool, plus one length and the leader hose. Refer to
Figure 5.
Leader
Hose
Swivel
Assembly
Figure 2
Figure 3
The S5™ Sucon Side Pool Cleaner body is shipped as one
piece, making cleaner assembly a simple and quick process.
50.8cm
(20 in)
ASSEMBLING THE CLEANER
Hose must reach furthest point in pool
— —
plus one length
plus
leader
hose
Figure 5
Figure 4
