POOL PREPARATION
The chlorinator requires a minimum 3000ppm of salt but the recommended level is 4000ppm therefore add 4kgs of salt for
every 1000 litres of water (a typical pool of around 50,000 litres requires 200kg of salt).
Salt should always be added at the shallow end of the pool and allowed to dissolve. Running the pump will mix the water
and speed the dissolving process.
WARNING: Never add salt to the skimmer box!!
NOTE : Plug the pump directly into a power outlet (bypass the Chlorinator) and run for 8-10 hours to ensure the salt is
dissolved prior to running the chlorinator.
When the salt is dissolved, connect the pump to the chlorinator and run it on maximum chlorine output. Check that the low
salt light is not on. If it is, check again in 24 hours.
NOTE
The VX chkorinator will come factory set as a Timer model which enables you to set timers to turn the unit on and off
as required. If you do not want to use this option and don’t want to use the timer option you can easily turn the option
off in setting up the chlorinator. Refer to User Mode (S MODEL ONLY) PAGE 7
USER PANEL
The user panel can be broken down into 5 separate areas :
- Programming area for setting the clock and on periods(on T models)
- Chlorine Output Controls for setting the chlorine output level and to activate the Safety Backwash feature
- Warnings display to indicate that there is no flow to the cell or there is insufficient salt in the pool
- User Mode for manual control of the pump/Chlorinator or to select Spa mode.
- Chlorine Production Level indicates the amount of chlorine being produced.
Once programmed, you will generally only use the User Mode and Chlorine Output control.
