Specific Symbols and Signal Words
Other Product Symbols
The manufacturer reserves the right to make design changes for
product improvement. This manual may not reflect all details of
these improvements.
WARNING: High Pressure. System contents
under pressure. Can cause serious injury and burns
or equipment and property damage. Relieve
pressure before servicing.
WARNING: Disconnect electrical power at
external source. Failure to do so can cause
electrical shock.
DANGER: High Voltage. Can cause serious
injury, including death. Disconnect electrical
power at external source before servicing
WARNING: Hot Surface. Can cause serious
injury and burns. Wear heat resistant clothing,
gloves and safety goggles.
PE
+
-
On
Tank
Set Temp
Tank Heater
Off
Heated Hose
Standby Temp
Alarm
Ground
Applicator
Overtemp
Actual Temp
Protective Earth
Pump Motor
Adhesive Flow
Source Power
Valve Group
Manual Task
Input
Output
© Copyright Astro Packaging 2009 KB30, KB50 and KB100 Series Hot Melt Units 19600-159 Rev. A 04/09/09 3
