ASUNA 5100 - Parts List

No.
DESCRIPTION
QTY
No.
DESCRIPTION
QTY
1
Main frame
1
46
Flat washer M6 (912x^6.5 x 2.0)
2
2
Seat
1
47
Hex screw (M6xP1.0x80L)
2
3
Seat slider
1
48
Sweat guard (right)
1
4
Seat post
1
49
Sweat guard (left)
1
5
Bushing (seat slider)
1
50
Outer chain guard
1
6
Seat height adjustment knob
1
51
Inner chain guard (front)
1
7
Bushing (seat post/handlebar)
2
52
Inner chain guard
1
8
Handlebar
1
53
Flat cross head screw (M5x P0.8x10L)
4
9
Handlebar post
1
54
Self-Tapping screw (M4x16L)
2
10
Flat washer M8(D8.1xD16x1.6T)
4
55
Flat cross head screw (M5xP0.8X25L)
1
11
Hex-socket screw (M8xP1.25x15L)
3
56
Brake knob cover
1
12L/R
Pedals (left & right)
2
57
Flat cross head screw (M-4xP0.7x10L)
1
13
Front stabilizer
1
58
Resistance knob
1
14
Flat Washer M8(19φ8.5*1T)
12
59
Brake cover
1
15
Hex-socket screw (M8xP1.25x45L)
4
60
Brake rod (SUS304 D10x266L)
1
16
Nylon nut (M8*P1.25)
6
61
Compression spring (D12*40L*1.5T)
1
17
Hex screw (M8xP1.25x45L)
2
62
Square plastic bushing
1
18
Transportation wheel
2
63
Nylon nut (M8xP2.0)
1
19
Hex nut (93/8"*16T*8T)
4
64
Nylon nut (M5*P0.8)
1
20
Leveler foot
4
65
Nylon nut (M4*P0.7)
2
21
Rear stabilizer
1
66
Brake block (right)
1
22
Water bottle holder
2
67
Permanent magnet (CG-02)
6
23
Flat cross head screw (M5xP0.8 x 16L)
12
68
Brake block (left)
1
24
Crank bolt (8MM Hex)
2
69
Flat cross head screw (M4*P0.7*40L)
2
25
Hex-socket screw (M8xP1.25x10L)
1
70
Nylon nut (M10*P1.5)
1
26
Left crank arm
1
71
Flat washer (D16*D10.2*1.0T)
2
27
Right crank arm (fixed set)
1
72
Bearing (LF-1910ZZ)
2
28
Sprocket / pulley
1
73
Brake gasket assembly
1
29
V-Ribbed belt
1
74
Torsion spring 2.0
1
30
Bottom bracket set
1
75
Hex-socket screw (M10*P1.5*45L)
1
31
Bottom bracket locknut
1
76
Flat cross head screw (M4*P0.7*10L)
4
32
Front sprocket/pulley
1
77
Brake block connection piece
2
33
Hub set
1
78
Copper bushing
4
34
Hex-socket screw (M5xP0.8x16L)
6
79
Brake adjustment block
2
35
Aluminum ring (flywheel)
1
80
Seat slider adjustment knob
1
36
Flywheel
1
81
Handlebar adjustment knob
1
37
Permanent magnet
1
82
Flywheel axel
1
38
Hub shell plastic cover
1
83
Flywheel bearing
3
39
Idler pulley arm
1
84
Idler pulley nut
1
40
Bushing
1
85
Bottom bracket bearing
2
41
Bearing (6003LLU)
4
86
Left cup of bottom bracket
1
42
Circlip
2
87
Bottom bracket locknut
1
43
Flange nut (BC y 3/8"*26T*8T)
2
88
Dust cover of bottom bracket set
1
44
Washer (910.5>20*1.5T)
2
89
Right cup of bottom bracket
1
45
Belt adjustment bracket
2
90
Guide rail pulley
1
