Chapter 2 – Hardware Information 13
Maker Board UPS-EHL01 UP Squared V2
Pin
Signal
Pin
Signal
9
GND
10
NC
11
NC
12
+3.3V_NGFF
13
NC
14
+3.3V_NGFF
15
GND
16
+3.3V_NGFF
17
NC
18
+3.3V_NGFF
19
NC
20
NC
21
GND
22
NC
23
NC
24
NC
25
NC
26
NC
27
GND
28
NC
29
PCIE_P5_RX_DN
30
NC
31
PCIE_P5_RX_DP
32
NC
33
GND
34
NC
35
PCIE_P5_TX_DN
36
NC
37
PCIE_P5_TX_DP
38
GPPC_E_4_SATA_DEVSLP_0
39
GND
40
SMB_CLK_1V8
41
PCIE_P4_RX_DN
42
SMB_DATA_1V8
43
PCIE_P4_RX_DP
44
NC
45
GND
46
NC
47
PCIE_P4_TX_DN
48
NC
49
PCIE_P4_TX_DP
50
BUF_PLT_RST#
51
GND
52
NC
53
PCIE_CLK4_DN
54
WAKE_N
55
PCIE_CLK4_DP
56
NC
57
GND
58
NC
59
KEY
60
KEY
61
KEY
62
KEY
