Asus AAEON UP Squared V2 User Manual

Chapter 2 – Hardware Information 19
Maker Board UPS-EHL01 UP Squared V2
Pin
Signal
Pin
Signal
29
KEY
30
KEY
31
KEY
32
UART0_TXD
33
GND
34
UART0_CTS
35
PCIE_P6_TXP
36
UART0_RTS
37
PCIE_P6_TXN
38
NC
39
GND
40
NC
41
PCIE_P6_RXP
42
NC
43
PCIE_P6_RXN
44
NC
45
GND
46
NC
47
PCIE_CLKP0
48
NC
49
PCIE_CLKN0
50
M.2_BTWIFI_SUS_CLK
51
GND
52
PLT_RST#
53
CLKREQ_N
54
NC
55
WAKE_N
56
NC
57
GND
58
NC
59
PCIE_P7_TXP
60
NC
61
PCIE_P7_TXN
62
NC
63
GND
64
NC
65
PCIE_P7_RXP
66
NC
67
PCIE_P7_RXN
68
NC
69
GND
70
NC
71
NC
72
+3P3VAUX_WIFI
73
NC
74
+3P3VAUX_WIFI
75
GND
-
-
