Appendix B – Cables and Connectors 37
Maker Board UPS-EHL01 UP Squared V2
Location
Connector
Function
Description
Mating Cable
PN/
CONN PN
Mating Cable Description
CN16
1655302025
SATA PWR
1702150155
1702150306
(TF)Power Cable.15P
SATA(F).2P 2.0mm
Housing(PH).15cm
(TF)Power Cable.15P
SATA(F).2P 2.0mm
Housing(PH).30cm
CN17
1655906033
Front Panel
170X000306
(TF)Cable.to 6P 1.00mm
housing.Power switch
cable.SW w/green
LED.20cm.FLYINGWAY.FWAA
-1348
CN18
1655906033
Audio
170X000382
(TF)Cable.6P.Pitch=1.0mm.15
0mm.FLYINGWAY.FWAA-147
3.Audio Jack Cable
LED1
1304300140
PWR LED
LED2
1304300140
LED2
LED3
1304200043
LED3
LED4
1304101440
LED4
LED5
1304000043
LED5
JP1
165300310G
Auto-Power Button
Selection
