Asus H97M-PLUS - LPT and M.2 Connectors

10. LPT connector (26-1 pin LPT)
TheLPT(LinePrintingTerminal)connectorsupportsdevicessuchasaprinter.LPT
standardizesasIEEE1284,whichistheparallelportinterfaceonIBMPC-compatible
computers.
H97M-PLUS
LPT
PIN 1
SLCT PE BUSY ACK# PD7 PD6 PD5 PD4 PD3 PD2 PD1 PD0 STB#
GND GND GND GND GND GND GND GND
SLIN#
INIT#
ERR#
AFD
H97M-PLUS Parallel Port Connector
11. SATA M.2 connector
ThisconnectorisforaSATAM.2-compliantsolid-statedrive(SSD).TheM.2standard
supportsdatatransferspeedsupto10.0Gb/s.
H97M-PLUS
H97M-PLUS M.2(SOCKET3)
M.2(SOCKET3)
• ThissocketsupportsMKeyandtype2260/2280storagedevices.
• TheM.2Socket3sharesbandwidthwithSATAports5and6.Refertosection2.6.3
PCH Storage Configuration of this user guide for more details.
• WhenusingIntel
®
DesktopResponsivenesstechnologieswithPCIeM.2device,
ensuretosetuptheWindows
®
UEFIoperatingsystemunderRAIDmode.
TheM.2(NGFF)SSDmoduleispurchasedseparately.
1-18
Chapter 1: Product introduction
