CPU C states [Auto]
[Auto] Automatic conguration.
[Enabled] Enables the CPU C states.
[Disabled] Disables the CPU C states..
The following items appear only when you set the CPU C states to [Enabled].
Enhanced C1 state [Enabled]
[Enabled] Enables enhanced C1 state.
[Disabled] Disables enhanced C1 state.
CPU C3 Report [Enabled]
Allows you to disable or enable the CPU C3 report to OS. Conguration
options: [Enabled] [Disabled]
CPU C6 Report [Enabled]
Allows you to disable or enable the CPU C6 report to OS. Conguration
options: [Enabled] [Disabled]
C6 Latency [Short]
Allows you to choose short or long latency for C6. Conguration options:
[Short] [Long]
CPU C7 Report [CPU C7s]
Allows you to disable or enable the CPU C7 report to OS. Conguration
options: [Disabled] [CPU C7] [CPU C7s]
C7 Latency [Long]
Allows you to choose short or long latency for C6. Conguration options:
[Short] [Long]
Package C State Support [Auto]
Allows you to disable or enable the whole C‑State package support.
Conguration options: [Auto] [Enabled] [C0/C1] [C2] [C3] [C6] [CPU C7]
[CPU C7s]
2.6.2 PCH Configuration
PCI Express Configuration
PCI-E Speed [Auto]
Allows you to select the PCI Express port speed. Conguration options: [Auto] [Gen1]
[Gen2].
Intel Rapid Start Technology
Intel
®
Rapid Start Technology [Disabled]
Allows you to enable or disable Intel
®
Rapid Start Technology. Conguration options:
[Disabled] [Enabled].
The following items appear only when you set the Intel
®
Rapid Start Technology to
[Enabled].
Entry on S3 RTC Wake [Enabled]
The system automatically wakes up and set to Rapid Start Technology S4
mode. Conguration options: [Enabled] [Disabled].
