Asus H97M-PLUS - Ai Tweaker Menu: CPU Voltages; CPU Core, Cache, and Graphics Voltages

2.5.14 CPU Core Voltage [Auto]
This item allows you to set the CPU Core voltage. Increase the core voltage when increasing
the ring frequency. Conguration options: [Auto] [Manual Mode] [Offset Mode].
CPU Core Voltage Override [Auto]
This item appears only when you set the CPU Core Voltage to [Manual Mode] and allows you
to set the CPU Core voltage override. The values range from 0.001V to 1.920V with a 0.001V
interval.
Offset Mode Sign [+]
This item appears only when you set the CPU Core Voltage to [Offset Mode] and allows you
to set the offset mode sign. Conguration options: [+] [‑].
CPU Core Voltage Offset [Auto]
This item appears only when you set the CPU Core Voltage to [Offset Mode] and
allows you to set the CPU core voltage offset. Use the <+> or <‑> keys to adjust the
value. The values range from 0.001V to 0.999V with a 0.001V interval.
2.5.15 CPU Cache Voltage [Auto]
This item allows you to set the CPU Cache voltage. Increase the cache voltage when
increasing the ring frequency. Conguration options: [Auto] [Manual Mode] [Offset Mode].
CPU Cache Voltage Override [Auto]
This item appears only when you set the CPU Cache Voltage to [Manual Mode] and allows
you to set the CPU Cache voltage override. The values range from 0.001V to 1.920V with a
0.001V interval.
Offset Mode Sign [+]
This item appears only when you set the CPU Cache Voltage to [Offset Mode] and allows
you to set the offset mode sign. Conguration options: [+] [‑]
CPU Cache Voltage Offset
This item appears only when you set the CPU Cache Voltage to [Offset Mode] and
allows you to set the CPU cache voltage offset. Use the <+> or <‑> keys to adjust the
value. The values range from 0.001V to 0.999V with a 0.001V interval.
2.5.16 CPU Graphics Voltage [Auto]
This item allows you to set the CPU graphics voltage. Increase the graphics voltage when
increasing the iGPU frequency. Conguration options: [Auto] [Manual Mode] [Offset Mode]
[Adaptive Mode].
[Adaptive Mode] is available for some specic CPU types.
CPU Graphics Voltage Override [Auto]
This item appears only when you set the CPU Graphics Voltage to [Manual Mode] and
allows you to set the CPU graphics voltage override. The values range from 0.001V to
1.920V with a 0.001V interval.
