ASUS P5E-VM DO 2-25
USB Functions [Enabled]
Allows you to enable or disable USB functions.
Conguration options: [Enabled] [Disabled].
USB 2.0 Controller [Enabled]
Allows you to enable or disable the USB 2.0 controller. Conguration options:
[Enabled] [Disabled].
USB 2.0 Controller Mode [HiSpeed]
Allows you to congure the USB 2.0 controller in HiSpeed (480 Mbps) or Full
Speed (12 Mbps). Conguration options: [FullSpeed] [HiSpeed].
BIOS EHCI Hand-Off [Enabled]
Allows you to enable support for operating systems without an EHCI hand-off
feature. Conguration options: [Disabled] [Enabled].
Port 64/60 Emulation [Disabled]
Allows you to disable or enable the I/O port 60h/64h emulation support. This
should be enabled for the complete USB keyboard legacy support for non-USB
aware OSes. Conguration options: [Disabled] [Enabled].
Legacy USB Support [Auto]
Allows you to enable or disable support for USB devices on legacy operating
systems (OS). Setting to Auto allows the system to detect the presence of USB
devices at startup. If detected, the USB controller legacy mode is enabled. If no
USB device is detected, the legacy USB support is disabled.
Conguration options: [Disabled] [Enabled] [Auto]
The Module Version and USB Devices Enabled items show the
auto-detected values. If no USB device is detected, the item shows None.
2.4.2 USB Conguration
The items in this menu allow you to change the USB-related features. Select an
item then press <Enter> to display the conguration options.
USB Conguration
USB Devices Enabled:
None
USB Functions [Enabled]
USB 2.0 Controller [HiSpeed]
USB 2.0 Controller Mode [HiSpeed]
BIOS EHCI Hand-Off [Enabled]
Port 64/60 Emulation [Disabled]
Legacy USB Support [Auto]
Enables support for
legacy USB. AUTO
option disables
legacy support if
no USB devices are
connected.
The following items appear only when the USB Function item is set to
[Enabled].
