Asus P8H67-M PRO User Manual

ASUS P8H67-M PRO 1-1
Chapter 1
Product introduction
Motherboard ASUS P8H67-M PRO motherboard
Cables 2 x Serial ATA 6.0Gb/s cables
1 x Ultra DMA 133/100 cable
Accessories 1 x I/O shield
Application DVD ASUS motherboard support DVD
Documentation User Manual
If any of the above items is damaged or missing, contact your retailer.
1.3 Special features
1.3.1 Product highlights
LGA1155 socket for Intel
®
Second Generation Core™ i7/
Core™ i5/ Core™ i3 Processors
This motherboard supports the Intel
®
Second Generation Core™ i7/
Core™ i5/ Core™ i3 processors in LGA1155 package with memory and
PCI Express controllers integrated to support 2-channel (4 DIMMs) DDR3
memory and 16 PCI Express 2.0 lanes. This provides great graphics
performance. Intel
®
Second Generation Core™ i7/ Core™ i5/ Core™ i3
processors are among the most powerful and energy efcient CPUs in
the world.
1.1 Welcome!
Thank you for buying an ASUS
®
P8H67-M PRO motherboard!
The motherboard delivers a host of new features and latest technologies, making it another
standout in the long line of ASUS quality motherboards!
Before you start installing the motherboard, and hardware devices on it, check the items in
your package with the list below.
1.2 Package contents
Check your motherboard package for the following items.

Asus P8H67-M PRO Specifications

General

Form Factor	Micro ATX
Chipset	Intel H67
Socket	LGA 1155
Maximum Memory	32GB
Memory Type	DDR3
PCI Express x16 Slots	1 x PCIe 2.0 x16
PCIe 2.0 x1 Slots	2
PCI Slots	1
SATA 3Gb/s Ports	4
SATA 6Gb/s Ports	2
USB 3.0 Ports	2 (on back panel)
Audio Chipset	Realtek ALC892
RAID Support	RAID 0, 1, 5, 10
Multi-GPU Support	No
Memory Standard	DDR3 1333/1066
USB 2.0 Ports	12
Integrated Graphics	Yes (Requires a processor with integrated graphics)
Audio	8-Channel High Definition Audio
Ethernet	1 x Gigabit LAN Controller
Memory Slots	4 x DIMM
