Service Manual
Appendix
Wiring and connection diagram
1. LCP RF connector (lower)
2. Mini LED/Aura LED connector
3. Wireless charger connector
4. Panel connector
5. Lower 24-pin connector
6. USB Type-C connector
7. Battery connector
8. LCP RF connector (upper)
9. Upper 34-pin connector
10. Tele camera connector
11. Dual camera 30-pin connector
12. Dual camera 40-pin connector
