Microphone
Before you begin
1. Read the Safety notices and Guidelines.
2. The microphones are positioned in three locations as shown on
the illustration above:
• Upper sub-board (top)
• Lower sub-board (middle)
• Motherboard (bottom)
3. Remove the following components:
• Back cover
• Speaker
• USB charging connector (EC)
